AA34 Series Universal Radio Interface
SM36 Installation and Operation Manual
Section 2 Rev: 1.01 Issue 4 Page 2-7
ENG-FORM: 805-0121.DOT
CONFIDENTIAL AND PROPRIETARY TO NORTHERN AIRBORNE TECHNOLOGY LTD.
2.6 Accessories Required But Not Supplied
Installation kit p/n AA34-IKC (crimp) is required to complete the installation. The kit consists of the
following:
AA34-IKC 25 Pin D-min Female Crimp Kit (NAT Part No D25SL-IKC)
Quantity Description NAT Part No.
1 D-min 25 Socket Housing 20-21-025
25 MS Crimp Socket 20-26-901
1* Jack Screw Set 20-27-002
1* Lock Clip Set 20-27-004
1 25 Pin Connector Hood 20-29-026
* Use as required.
2.7 Installation Drawings
Use of the "#" symbol in the REV. column indicates that the document is listed elsewhere in the manual.
Refer to the applicable NAT Part No. to locate the referenced document.
DOCUMENT REV. DESCRIPTION TYPE SERIAL/
MOD NO
AA34-200
AA34\200\403-0 1.03 Universal Radio Interface Interconnect All
AA34\200\405-0 1.02 Universal Radio Interface Connector Map All
AA34\200\922-0 1.02 Universal Radio Interface Mechanical Installation All
AA34-300
AA34\300\403-0 1.00 Universal Radio Interface Interconnect All
AA34\300\405-0 1.00 Universal Radio Interface Connector Map All
AA34\300\521-0 1.01 Universal Radio Interface Environmental Qual. Form 20001 and up
AA34\300\922-0 1.00 Universal Radio Interface Mechanical Installation Up to 20000
AA34\300\922-0 1.10 Universal Radio Interface Mechanical Installation 20001 - 30859
AA34\300\922-0 1.20 Universal Radio Interface Mechanical Installation MOD 4
AA34\300\922-0 1.30 Universal Radio Interface Mechanical Installation MOD 5
AA34-301
AA34\301\403-0 1.00 Universal Radio Interface Interconnect All
AA34\301\405-0 1.00 Universal Radio Interface Connector Map All
AA34\300\922-0 #
Section 2 ends following the above documents
