Carrier Output Power 1 or 10 W
Time-out Timer 30-300 s (Factory Set to 60 s)
Duty Cycle 20% (1 min Tx, 4 min Rx.)
VSWR 20:1 (30 sec duration - undamaged)
Rated Deviation ±5.0 kHz (25 kHz BW)
±2.5 kHz (12.5 kHz BW)
Audio Input Sensitivity 100 mV rms (60% of rated deviation)
Sidetone Audio Output Power:
25 mW (Adjustable)
Specifications (Cont’)
Refer to Install and Operation Manual, Description §1.4 for more details.
