Power +28 Vdc ( Transmit: 2.6 A max.)
Lights +28 Vdc, 300 mA max.
Frequency Range 136.0000 - 173.9975 MHz
Operating Modes Project 25 and Analog Simplex or Semi-Duplex
Channels 255 max. (main) (Zones: 16 max.)
Plus two guard channels
Analogue Tones CTCSS - 42 tones from 67.0 to 254.8 Hz
CDCSS - 83 data patterns
Remote Interface RS232C Serial Data Bus
RF Impedance 50 ohms
Channel Increments 2.5 / 6.25 kHz
Channel Bandwidth 12.5 / 25 kHz
Scan Capability 16 channels max. 1 home, 1 priority, 14 list,
8 chan/sec
Audio Output Power 100 mW (600 ohms)
Guard Audio Output Power, minimum: 10 mW (adjustable)
Specifications
