Chapter 1 Introduction and Quick Start
PCI-MXI-2 for Linux 1-10 ni.com
Table 1-2. PCI-MXI-2 Universal Hardware Default Settings
Hardware Component Default Setting
SW1 Switch 1 (FOV) OFF: PCI-MXI-2 boots off the
user-configured half of the EEPROM.
SW1 Switch 2 (TST) OFF: Factory configuration of the
EEPROM is protected.
SW1 Switch 3 (POS) OFF: Do not alter this setting.
SW1 Switch 4 (CT) ON: Do not alter this setting.
DRAM SODIMM Installed Per customer order
Table 1-3. PCI-MXI-2 Logical Address Configuration Editor Default Settings
Editor Field Default Setting
Logical Address 0
Device Type MBD
Address Space A16
VXI Shared RAM Size 0 KB
Shared RAM Pool 0 KB
Lower Half Window Byte Swapping Disabled (non-swapped)
Lower Half Window Memory Select System Memory
Upper Half Window Byte Swapping Disabled (non-swapped)
Upper Half Window Memory Select System Memory
Resource Manager Delay 5 s
Map Upper/Lower Halves to Same Address Disabled
