National Instruments MXI-2 Series User Manual

Chapter 1 Introduction and Quick Start
© National Instruments Corporation 1-11 PCI-MXI-2 for Linux
Table 1-4. PCI-MXI-2 Device Configuration Editor Default Settings
Editor Field Default Setting
Default Controller (LA-1) First Remote Controller
System IRQ Level 1
Servant Area Size 0
Number of Handlers 1
Number of Interrupters 0
Protocol Register 0xFF0
Read Protocol Response 0x8448
Table 1-5. PCI-MXI-2 Bus Configuration Editor Default Settings
Editor Field Default Setting
MXI System Controller Auto
MXI Bus Timeout Value 1 ms
MXI CLK10 Receive
MXI Transfer Limit Unlimited
VXImove uses Synchronous MXI Enabled
MXI-2 Auto Retry Enabled
A24/A32 Write Posting Disabled
User Window Size 64 KB
Driver Window Size 32 KB
Expansion ROM Enabled
