National Instruments MXI-Express Gen-3 x16

Slot requirements One peripheral slot (PXI Express or
CompactPCI Express)
Compatibility Fully compatible with the PXI Express
Hardware Specification, Revision 1.0; PICMG
CompactPCI Express EXP.0 R2.0
Specification; and the PCI Express External
Cable Specification, Revision 3.0
Weight 0.35 kg (0.76 lb) typical
Power Requirements
Power Rail Typical Current Maximum Current
+3.3 V 150 mA 250 mA
+12 V
1
850 mA 2200 mA
+5 V
AUX
5 mA 15 mA
1
Not including the power consumed by an active cable. NI copper cables (785550-0x) are
passive.
Environment
Maximum altitude 2,000 m
Pollution Degree 2
Indoor use only.
Operating Environment
Ambient temperature range 0 °C to 55 °C (Tested in accordance with
IEC-60068-2-1 and IEC-60068-2-2. Meets
MIL-PRF-28800F Class 3 low temperature
limit and MIL-PRF-28800F Class 2 high
temperature limit.)
Relative humidity range 10% to 90%, noncondensing (Tested in
accordance with IEC-60068-2-56.)
Storage Environment
Ambient temperature range -40 °C to 71 °C (Tested in accordance with
IEC-60068-2-1 and IEC-60068-2-2. Meets
MIL-PRF-28800F Class 3 limits.)
Relative humidity range 5% to 95%, noncondensing (Tested in
accordance with IEC-60068-2-56.)
MXI-Express Gen-3 x16 User Manual | © National Instruments | 33
