Functional Block Diagram
Figure 1. PCIe-8398 (156877x-01L) Block Diagram
MXI-Express
Gen-3 x16
PWR/LNK
Status LED
PCI Express Gen-3 x16
PCI Express Gen-3 x16
PCI Express
Switch
4 | ni.com | MXI-Express Gen-3 x16 User Manual
