Appendix A Device-Specific Information
M Series User Manual A-26 ni.com
Note For more information about default NI-DAQmx counter inputs, refer to Connecting
Counter Signals in the NI-DAQmx Help or the LabVIEW Help in version 8.0 or later.
PCI/PXI-6224 Specifications
Refer to the NI 622x Specifications for more detailed information about the
PCI/PXI-6224 device.
PCI/PXI-6224 Accessory and Cabling Options
This section describes some cable and accessory options for M Series
devices with two 68-pin connectors, such as the PCI/PXI-6224. Refer to
ni.com for other accessory options including new devices.
Table A-6. Default NI-DAQmx Counter/Timer Pins
Counter/Timer Signal
Default Connector 0 Pin Number
(Name)
CTR 0 SRC 37 (PFI 8)
CTR 0 GATE 3 (PFI 9)
CTR 0 AUX 45 (PFI 10)
CTR 0 OUT 2 (PFI 12)
CTR 0 A 37 (PFI 8)
CTR 0 Z 3 (PFI 9)
CTR 0 B 45 (PFI 10)
CTR 1 SRC 42 (PFI 3)
CTR 1 GATE 41 (PFI 4)
CTR 1 AUX 46 (PFI 11)
CTR 1 OUT 40 (PFI 13)
CTR 1 A 42 (PFI 3)
CTR 1 Z 41 (PFI 4)
CTR 1 B 46 (PFI 11)
FREQ OUT 1 (PFI 14)
