High-resolution filter response
1,2
1
This image is provided courtesy of Linear Technology Corp.
2
High-speed filter response has the same characteristics as the high-resolution filter
response except that the first notch is at 14 kHz.
–20
–0
–40
–60
–80
–100
–120
–140
0 60 120
Differential Input
Signal Frequency (Hz)
Normal Mode Rejection (dB)
180 240
