© National Instruments Corp. 7 NI 9217 Operating Instructions and Specifications
Connecting the NI 9217
The NI 9217 has a 16-terminal, detachable screw-terminal
connector that provides connections for four RTD channels.
Figure 2. NI 9217 Terminal Assignments
EX0
RTD0+
RTD0–
COM
EX1
RTD1+
RTD1–
COM
EX2
RTD2+
RTD2–
COM
EX3
RTD3+
RTD3–
COM
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
