Power Requirements

Caution The protection provided by the PCIe-6374 can be impaired if it is used in a manner not described in the user documentation.

Attention La protection apportée par le PCIe-6374 risque d'être endommagée s'il est utilisé d'une autre façon que celle décrite dans la documentation

utilisateur.

+3.3 V 4.0 W

+12 V 13.2 W

Physical

Printed circuit board dimensions 16.8 cm × 11.1 cm (6.60 in. × 4.38 in.)

Weight 110 g (4.0 oz)

I/O connectors

PCIe device connector 68-Pos Right Angle Single Stack PCB-Mount VHDCI (Receptacle)

Cable connector 68-Pos Offset IDC Cable Connector (Plug) (SHC68-*)

Form factor Standard height, half length, single slot

Integrated air mover (fan) No

Note For more information about the connectors used for DAQ devices, refer to the document, NI DAQ Device Custom Cables, Replacement

Connectors, and Screws, by going to

ni.com/info and entering the Info Code rdspmb.

Environmental

This product meets the requirements of the following environmental standards for electrical equipment for measurement, control, and laboratory use.

Temperature

Operational, local

0 °C to 50 °C

(IEC 60068-2-1 and IEC 60068-2-2)

Storage -20 °C to 70 °C

(IEC 60068-2-1 and IEC 60068-2-2)

Operational humidity 10% to 90% RH, noncondensing

(IEC 60068-2-78)

Storage humidity 5% to 95% RH, noncondensing

(IEC 60068-2-78)

System slot airflow 0.4 m/s (80 LFM)

Pollution Degree 2

Maximum altitude 2,000 m (800 mbar) (at 25 °C ambient temperature)

Indoor use only.

Safety Compliance Standards

This product is designed to meet the requirements of the following electrical equipment safety standards for measurement, control, and laboratory use:

• IEC 61010-1, EN 61010-1

• UL 61010-1, CSA C22.2 No. 61010-1

Note For UL and other safety certifications, refer to the product label or the Product Certifications and Declarations section.

Electromagnetic Compatibility

This product meets the requirements of the following EMC standards for electrical equipment for measurement, control, and laboratory use:

• EN 61326-1 (IEC 61326-1): Class A emissions; Industrial immunity

• EN 55011 (CISPR 11): Group 1, Class A emissions

For PCI Express adapter cards with integrated air movers, NI defines the local operational ambient environment to be at the fan inlet. For cards without

integrated air movers, NI defines the local operational ambient environment to be 25 mm (1 in.) upstream of the leading edge of the card. For more

information about the local operational ambient environment definition for PCI Express adapter cards, visit ni.com/info and enter the Info Code

pcielocalambient.
