National Instruments PXI-8360 User Manual

© National Instruments Corporation 15 Set Up Your MXI-Express x1 System
Refer to Figure 5 for onboard LED locations.
Figure 5. NI PXIe-8364 (193970x-01L) Onboard LED Locations
Link Good LEDs—LEDs that indicate a successful cable link (LED 0) and
backplane link (LED 4).
Link Activity LEDs—LEDs that indicate link activity on the cable link
(LED 0) and the backplane link (LED 4).
PCIe Switch
PCIe Gen 1 x4
PCIe Gen 1 x1
MXI-Express x1
Copper
4
0
Link Good
4
0
Link Activity
Port 0 Port 4

National Instruments PXI-8360 Specifications

General

Brand	National Instruments
Model	PXI-8360
Category	PCI Card
Language	English
