National Instruments PXIe-5413 User Manual

Table 6. Passband Flatness Accuracy Verification (Continued)
Amplitude Range
(V
pk-pk
)
Frequency (MHz) As-Found Test
Limit (dB)
As-Left Test Limit
(dB)
5 1.040 0.05 — —
6 1 ±0.40 ±0.25
7 20 ±0.40 ±0.11
11 0.956 0.05 — —
12 1 ±0.40 ±0.25
13 20 ±0.40 ±0.11
17 0.867 0.05 — —
18 1 ±0.40 ±0.25
19 20 ±0.40 ±0.11
23 0.780 0.05 — —
24 1 ±0.40 ±0.25
25 20 ±0.40 ±0.11
29 0.321 0.05 — —
30 1 ±0.40 ±0.25
31 20 ±0.40 ±0.11
35 0.099 0.05 — —
36 1 ±0.40 ±0.25
37 20 ±0.40 ±0.11
1. Connect the SMA (m)-to-N (f) adapter to the power sensor.
2. Zero the power sensor.
a) Ensure that the power sensor is not connected to any signals.
b) Zero the power sensor using the built-in function, according to the power sensor
documentation.
3. Connect the power sensor with the SMA (m)-to-N (f) adapter attached to CH 0 of the
PXIe-5413.
Note Ensure the power sensor is supported to the extent that excessive strain
is not applied to the connected channel of the PXIe-5413 or to the power sensor
connector.
12 | ni.com | PXIe-5413 Calibration Procedure
