Caution Apply external signals only while the PXIe-5820 is powered on.
Applying external signals while the device is powered off may cause damage.
• Ensure you are properly grounded when manipulating cables connected to the PXIe-5820
I/Q IN connectors.
• If you are using nonisolated devices, such as a nonisolated RF antenna, ensure the devices
are maintained in a static-free environment.
• If you are using an active device, such as a preamplifier or switch routed to the
PXIe-5820 I/Q IN connectors, ensure that the device cannot generate signal transients
greater than the AC and DC specifications of the PXIe-5820 I/Q IN connectors.
Hardware Front Panel Connectors and Indicators
Figure 4. PXIe-5820 Front Panel
NI PXIe-5820
Vector Signal Transceiver
Baseband IQ, 1.25 GS/s
REF
OUT
I/Q OUT
PFI 0
DIO
REF
IN
I+
I–
Q+
Q–
ACCESS ACTIVE
ESD
SENSITIVE
50 Ω
100 Ω DIFF
I/Q IN
I+
I–
Q+
Q–
100 Ω DIFF
50 Ω
8 | ni.com | PXIe-5820 Getting Started Guide
