PXIe-5655 Front Panel and LEDs
Figure 4. PXIe-5655 with SMA Front Panel
Table 11. PXIe-5655 Connector Descriptions
Connector Connector Type Description
REF OUT SMA (f) Output terminal that can
export a 100 MHz Reference
Clock.
ni.com
40
PXIe-5842 Getting Started
