Name: National Instruments PXIe-5842
Brand: National Instruments
Rating: 4 (1 reviews)

To Next Page

To Previous Page

Pin Signal Description

13 GND Ground reference for signals

12 DIO 3 Bidirectional digital I/O line

11 DIO 2 Bidirectional digital I/O line

10 GND Ground reference for signals

9 DIO 1 Bidirectional digital I/O line

8 DIO 0 Bidirectional digital I/O line

7 GND Ground reference for signals

6 GND Ground reference for signals

5 NC No connection

4 GND Ground reference for signals

3 GND Ground reference for signals

2 NC No connection

1 GND Ground reference for signals

PXIe-5842 Getting Started
