National Instruments R Series Getting Started Guide

Table 1. Recommended Cables and Accessories
Connector Type Connector Block Cables
Multifunction
Connector 0
(RMIO)
SCB-68A Noise
Rejecting, Shielded I/O
Connector Block
(782536-01)
• SHC68-68-RMIO Shielded Cable for the
Reconfigurable MIO Connector, 68 pin
D-Type to 68 pin VHDCI, 1m
(189588-01)
• SHC68-68-RMIO Shielded Cable for the
Reconfigurable MIO Connector, 68 pin
D-Type to 68 pin VHDCI, 2m
(189588-02)
Analog Output
Connector 2
(RAO)
Digital Connector
1 (RDIO)
SCB-68 HSDIO
Shielded 68-Pin
Connector Block for
Reconfigurable DIO &
HSDIO Products
(782914-01)
• SHC68-C68-RDIO2 Shielded High
Speed Digital Cable for the
Reconfigurable DIO Connector, 1m
(156166-01)
• SHC68-C68-RDIO2 Shielded High
Speed Digital Cable for the
Reconfigurable DIO Connector, 2m
(156166-02)
Note The SCB-68A DIP switches must be set for Direct Feedthrough mode for use
with R Series devices. Visit ni.com/info and enter the Info Code scb68acables for
more information on the SCB-68A accessory.
Note NI is not liable for connections that exceed any of the maximum ratings of
input or output signals on the NI PXIe-7868R and on the computer chassis. Refer to
the NI PXIe-7868R Specifications, available at ni.com/info for the maximum input
and output ratings for each signal.
NI PXIe-7868R Getting Started Guide | © National Instruments | 7
