© National Instruments | B-1
B
Hardware Configuration
This appendix describes how to configure and upgrade the RMC-8356 hardware.
Caution No user (operator) serviceable parts are inside the RMC-8356.
The hardware configuration and upgrade procedures described in this appendix must
be performed only by a qualified service technician.
Disconnect the power cord before servicing.
Motherboard Layout
The following is a layout of the RMC-8356 motherboard with jumper, connector, and LED
locations shown. Refer the following tables for descriptions. For detailed descriptions, pinout
information and jumper settings, refer to the Power Connections section.
Figure B-1 shows the key features of the RMC-8356 mainboard.
To Next Page
