National Instruments RMX-4120 User Manual

© National Instruments | A-3
RMX Programmable Power Supplies User Manual
Output power ............................................ 750 W
Voltage
Setting range
RMX-4120........................................ 0 to 31.5 V
RMX-4121........................................ 0 to 84 V
RMX-4122........................................ 0 to 241.5 V
RMX-4123........................................ 0 to 682.5 V
Setting accuracy........................................ ±(0.05% of setting +0.05% of rtg)
Line regulation
1
RMX-4120........................................ ±5 mV
RMX-4121........................................ ±10 mV
RMX-4122........................................ ±25 mV
RMX-4123........................................ ±67 mV
Load regulation
2
RMX-4120........................................ ±5 mV
RMX-4121........................................ ±10 mV
RMX-4122........................................ ±25 mV
RMX-4123........................................ ±67 mV
Transient response
3
RMX-4120/4121............................... 1 ms or less
RMX-4122/4123............................... 7 ms or less
Ripple noise
(p-p)
4
RMX-4120.................................. 60 mV
RMX-4121.................................. 80 mV
RMX-4122.................................. 120 mV
RMX-4123.................................. 330 mV
(rms)
5
RMX-4120/4121......................... 8 mV
RMX-4122.................................. 25 mV
RMX-4123.................................. 60 mV
Rise time
Rated load......................................... 100 ms
No load ............................................. 100 ms
1
85 VAC to 135 VAC or 170 VAC to 265 VAC, fixed load.
2
The amount of change that occurs when the load is changed from no load to rated load (rated output
power/rated output voltage) with rated output voltage. The value is measured at the sensing point.
3
The amount of time required for the output voltage to return to a value within “rated output voltage ± (0.1%
+10 mV).” The load current fluctuation is 50% to 100% of the maximum current with the set output voltage.
4
When the measurement frequency bandwidth is 10 Hz to 20 MHz.
5
When the measurement frequency bandwidth is 10 Hz to 1 MHz.
