Verifying the Kit Contents
6
54
31
2
TX OUTPUT MAX +20 dBm, RX INPUT MAX -15 dBm, ALL RF PORTS 50 Ω
RF 0
TX1 RX1
RX2
TX1 RX1
RX2
RF 1
NI USRP-2901
70 MHz–6 GHz
Designed by Ettus Research
1. USRP-2900/2901 Device
2. AC/DC Power Supply (Included Only in
USRP-2901 Kits)
3. USB 3.0 Cable
4. SMA (m)-to-SMA (m) Cable
5. 30 dB SMA Attenuator
6. USRP-2900/2901 Getting Started Guide (This
Document) and Safety, Environmental, and
Regulatory Information Document
Other Required Item(s)
In addition to the kit contents, you must provide a computer with available gigabit Ethernet
interface.
Optional Items
• Additional SMA (m)-to-SMA (m) cables to connect both channels with external devices
or to use the REF IN and PPS IN signals
• 6 V, 3 A external DC power connector
Environmental Guidelines
Notice This model is intended for use in indoor applications only.
USRP-2900/2901 Getting Started Guide | © National Instruments | 3
