6 Setting Up
Figure 8: Preferences Button
Routing the Audio Output
In order to properly output audio through your Kontrol S4, the audio output must be
routed correctly. Doing so may be easily accomplished by following these steps:
• Open the preferences menu by selecting the “gear”
button at the top right of the program window
(labeled “A” in Figure 8)
• Select “Audio Setup” in the preferences menu
(labeled “A” in Figure 9)
• Make sure “Traktor Kontrol S4” is selected under the Audio Device drop-down
menu (labeled “B” in Figure 9)
• Select “Output Routing” in the preferences menu (labeled “A” in Figure 10)
• Make sure the mixing mode is set to “Internal” (labeled “B” in Figure 10)
Connecting Speakers
Once the audio output is routed correctly as
explained above, the audio is outputted through the
Kontrol S4’s main outputs (Figure 11).
Plug your speakers into the back of the Kontrol S4
either by stereo ¼” cables (labeled “A” in Figure 11),
or stereo RCA cables (labeled “B” in Figure 11).
Keep in mind that these outputs do not provide
power and require that your choice of speakers be self-powered (active speakers) or
amplified externally (passive speakers).
Figure 10: Output Routing
Figure 9: Audio Setup
Figure 11: Kontrol S4 Outputs
A
A
B
B
A
B
A
