5
Nautilus NS700X
PARTS LIST / BOX CONTENTS
1 Rear Base Frame .................................................................1
2 Rear Top Frame ...................................................................1
3 Rear Support Upright A .....................................................1
4 Rear Support Upright B .....................................................
1
5 Rear Upright ........................................................................1
6 Top Beam ............................................................................. 1
7 Front Upright .......................................................................1
8 Leg Extension Frame ..........................................................
1
9 Main Base ........................................................................... 1
10 Backing Plate ...................................................................... 3
11 Corner Plate ........................................................................ 1
12 Connecting Plate A ............................................................
1
13 Connecting Plate B ............................................................
1
14 Connecting Plate C ............................................................. 1
15 Connecting Plate D ............................................................ 1
16 Connecting Plate E ............................................................. 1
17 Pec Fly Mount .....................................................................
1
18 Pec Fly Cam .........................................................................
2
19 Left Pec Fly Arm .................................................................. 1
20 Right Pec Fly Arm ...............................................................1
21 Pec Fly Handle ....................................................................2
22 Press Arm Support Assembly ..........................................
1
23 Press Arm ............................................................................
1
24 Right Press Arm Handle ....................................................1
25 Left Press Arm Handle ....................................................... 1
26 Press Arm Support Shaft .................................................. 1
27 Press Arm Pivot Shaft ........................................................
1
28 Seat Pad ...............................................................................
1
29 Back Pad .............................................................................. 1
30 T handle Pop Pin ................................................................. 1
31 Seat Adjuster ...................................................................... 1
32 Seat Cross Tube ................................................................. 1
33 Back Pad Tube .................................................................... 1
34 Back Pad Adjustment ........................................................1
35 Back Pad Adjustment Plate .............................................. 1
36 Pulley Bracket ..................................................................... 1
37 Pec Fly Pulley Bracket ....................................................... 1
38 Locking Roller Bar .............................................................. 1
39 Roller Bar ............................................................................. 1
40 Plastic Washer ................................................................... 2
41 PU Roller ..............................................................................2
42 8”L Foam Roller ................................................................... 2
43 PU Roller End Cap .............................................................. 2
44 Round End Cap .................................................................... 2
45 Power Spring Assembly .................................................... 1
46 Front Plate ........................................................................... 1
47 Guide Tube ..........................................................................
2
48 High/Low Pulley Adjuster ..................................................
1
49 Swivel Arm Assembly ........................................................ 2
50 Guide Rod Holder ............................................................... 2
51 Guide Rod ............................................................................ 4
52 Top Weight ..........................................................................2
53 Selector Stem ..................................................................... 2
54 TopWeight/SelectorRodAssembly(52/53) ...................... 2
55 Weight Stack Bottom Plate .............................................. 2
56 Weight Stack Bumper ....................................................... 4
57 6” Pulley ............................................................................... 1
58 41/2” Pulley .......................................................................... 27
59 Shroud .................................................................................. 1
59a Accessory Hook .................................................................. 3
60 Low Pulley Cover ................................................................ 2
61 Double Floating Pulley Bracket ........................................ 2
62 Cable Retaining Bracket ................................................... 2
63 Top Weight Pulley Housing .............................................. 1
64 Connecting Bench Bracket .............................................. 1
65 Bench Connecting Plate ................................................... 1
66 Weight Plate ........................................................................ 38
67 Plastic Cap ........................................................................... 4
68 Snap Cap .............................................................................. 2
Cable
69 #1 - Pull down Cable 263.75”L .......................................... 1
70 #2 - High/Low Pulley Cable 355.5”L ..................................
1
71 #3 - Pec Fly Cable 150.5”L .................................................1
72 #4 - Secondary Cable 179.5”L ............................................ 1
Hardware
73 Hex Bolt - 1/2” x 5 1/4”L ..................................................... 2
74 Hex Bolt - 1/2” x 3 1/4”L ..................................................... 1
75 Hex Bolt - 3/8” x 4 3/4”L ..................................................... 1
76 Hex Bolt - 3/8” x 4 1/4”L ..................................................... 5
77 Hex Bolt - 3/8” x 3 1/2”L ..................................................... 1
78 Hex Bolt - 3/8” x 3 1/4”L ..................................................... 8
79 Hex Bolt - 3/8” x 3”L ........................................................... 34
80 Hex Bolt - 3/8” x 2 3/4”L ..................................................... 6
81 Hex Bolt - 3/8” x 2 1/4”L ..................................................... 3
82 Hex Bolt - 3/8” x 2”L ........................................................... 17
83 Hex Bolt - 3/8” x 1 3/4”L ..................................................... 4
84 Hex Bolt - 3/8” x 1 1/2”L
with thread lock .................................................................. 3
85 Cap Head Allen Screw
3/8” x 3”L with thread lock ................................................ 2
86 Cap Head Allen Screw
1/4” x 1”L with thread lock ................................................ 4
87 Cap Head Allen Screw
1/4” x 1/2”L with thread lock ............................................ 2
88 Button Head Allen Screw
3/8” x 1 3/4”L ....................................................................... 2
89 Button Head Allen Screw
3/8” x 1”L (half threads) ..................................................... 1
90 Button Head Allen Screw
3/8” x 3/4”L ......................................................................... 4
91 Button Head Allen Screw
3/8” x 1/2”L with thread lock ............................................ 4
91a Button Head Self Tapping Screw 5/8” L ......................... 6
92 5/16” Set Screw 1/4”L ........................................................ 6
93 1 11/32 x 1/2” Flat Washer ................................................. 4
94 1/2” Flat Washer ................................................................. 6
95 3/8” Flat Washer ................................................................. 154
96 1/2” Lock Nut ....................................................................... 7
97 3/8” Lock Nut ....................................................................... 76
98 3/8” x 9/32t Lock Nut ..........................................................1
99 Shim Washer ....................................................................... 4
100 Step Spacer 19/32”H .......................................................... 8
101 Pulley Spacer 1/2”L ............................................................ 4
114 3/8” Curved Washer ............................................................ 4
Accessories
102 Lat Bar .................................................................................. 1
103 AB Strap ............................................................................... 1
104 Felt Back Ankle Strap ........................................................1
105 Handle Strap with 2 rings .................................................. 2
106 Cable Clip ............................................................................. 3
107 Weight Selector Pin ........................................................... 2
108 M4 Allen Wrench ............................................................... 1
109 M5 Allen Wrench ............................................................... 1
110 M6 Allen Wrench ............................................................... 1
111 M8 Allen Wrench ............................................................... 1
112 Weight Stack Decals .........................................................38
113 Shoulder Strap .................................................................... 2
# DESCRIPTION QTY # DESCRIPTION QTY
