NavePoint 42U - Reversing Front Door

www.NavePoint.com 5 customerservice@navepoint.com
-Reversing Front Door
1: Open the Front Door until it’s perpendicular to the Front Frame of the cabinet.
2: Disconnect the door’s ground wire.
3: Lift the door from the hinges and remove it from the Front Frame of the cabinet.
4: Remove the door hinges from the Front Frame.
5: Rotate both hinges 180 degrees and attach them on the opposite side of the Front Frame.
