NEP-2 Installation Manual | 11
NEP-2 network connection example
12-24V DC
Power
BR24
BSM-1/LBS-1
NSE/HDS
MFD
NSE/HDS
MFD
NEP-2
WM-2/LWX-1
(US only)
