9
1.5 Supply Connections
Refer to the following table for the NaviCirc supply connection
specications.
A
C D
B
A
C
D
B
Front view Side view
List Connection
A Hot Water Outlet PF ½”
B Cold Water Outlet PF ½”
C Hot Water Outlet PF ½”
D Cold Water Outlet PF ½”
Dimension (in) 5.62 x 3.93 x 2.19
Supply Connections
