FUEL 3100 / DIESEL 3200 Installation and Operation Manual
NAVMAN
3 The setup menus
3-1 Setup data
Use the setup menus, shown on the following
pages, to customize the unit to suit your
boat and your own preferences. To display or
change setup data:
1 From the main display, press ESC and ENT
together to start setup mode.
2 Press or one or more times to display
the setup menus.
3 Press ENT to select a setup menu.
4 Press or one or more times to display
the setup data for the setup menu.
5 If the boat has twin engines or twin tanks,
press ENT. Press one or more times to
display the port or starboard setup data.
6 To change the data:
i Press ENT; the data will blink.
ii Press or hold or to change the
value.
iii Press ENT to accept the new value or
press ESC to ignore your changes.
7 To display or change other setup data for
this setup menu, repeat steps 4, 5 and 6.
Then press ESC.
8 To display or change setup data for other
setup menus, repeat steps 2 to 6. Finally,
press ESC to return to the main display.
3-2 Initial Setup
1 In the FUEL menu set up the number of
fuel tanks. Select dUAL then Off (1 tank)
or On (2 tanks).Then select the number of
engines. Motor (1 or 2).
2 In the dSL SEn Menu identify the motors
by:
i Reset to single engine installation.
ii Select one motor (port or starboard),
then remove power from the
other motor’s diesel flow sensor
by unplugging the white coloured
connector.
iii Press and hold ENT for 2 seconds to
configure the motor, a beep will sound
when complete.
Repeat ii and iii for the other motor.
3 In the SPEEd menu identify the speed
input.None, GPS or Sen.
4 To reset all data to the factory defaults see
section 4-8
5 For single engine/ single tank diesel
installation factory defaults will work.
