Second Display Mount
This publication provides procedures for installing the Second Display Mount on an
NCR SelfServ™ 90 (7709) Kiosk.
Kit Contents
Part Number Description
497-0525141 7709–K015 Second Display Mount
795-0267101 5910 Display Mount
497-0512559 Cable, Display Port, 1.3 meters
497-0521788 Cable, Latch-N-Lok, USB +12V to USB A Split RJ50/DB9,
1.28meters
006-8611753 Nut, Kep, M4 (4 pcs)
006-8615964 Screw, M4x8, Machine, Phil, Pan, Steel, Black (4 pcs)
