NCR VOYIX CX5 Instructions

Pole Mount 3
Installation Procedure
The Quick-Release Bracket is an option to mount the Head. Another option is to mount
the Head directly on the hinge of the Pole Mount and the Cable Covers will be used.
• With Quick-Release Bracket below
• Without Quick-Release Bracket on page9
With Quick-Release Bracket
Warning: Disconnect the AC power cord from the AC outlet and wait 30 seconds
before servicing the terminal.
1. Lay the Display face down on a flat surface.
Note: Always use a soft material (cloth, foam) to protect the display screen when
placing the terminal face down.
2. Remove the Cable Cover.
a. Remove the two (2) screws that secure the Cable Cover to the Back Cover.
b. Rotate and unhook the Cable Cover from the Back Cover.
