2 XL7 Pole MountBracket, 7772/7773
2. Install the Customer Display Bracket on the Pole Mount (3 screws).
3. Connect the Cable to the XL7 Customer Display. Tighten the thumbscrew.
Note: Avoid overtightening the thumbscrew by turning it only until the silver
knurled portion touches the black plastic overmold. Overtightening the thumbscrew
damages the connector on the board.
