XL7 Pole MountBracket, 7772/7773 3
4. Route the XL7 Display Cable through the Customer Display Bracket and down the
Pole.
Note: If there’s a hole in the countertop, the cables can be routed through the
counter as well.
5. Install the Display on the Customer Display Bracket (4 screws).
Note: For clarity, the pole mount bracket is not shown in the illustration.
