NEC AccuSync AS192 - Controls

English-8
Controls
OSD (On-Screen Display) control buttons on the front of the monitor function
as follows:
1. Basic function at pressing each key
2. OSD structure
Shows OSD.
Shortcut to Brightness
adjustment window.
Button
OSD not
showing
Shortcut to Contrast adjust
window.
Input signal select.
OSD showing
(Icon selection stage)
Goes to Adjustment stage. Cursor goes to left. Cursor goes to right.
OSD showing
(Adjustment stage)
Goes to Icon selection stage. Adjust value decreases or
Cursor for adjust goes to left.
Adjust value increases or
Cursor for adjust goes to
right.
Reset operation.
Main Menu (Icon Select)
Sub Menu (Icon Select)
Press
“SELECT”
key
Press
“SELECT”
key
Press
“–” or “+”
Main Menu (Adjust)
Sub Menu (Adjust)
Press “SELECT” key
Press
“SELECT” key
Adjust by using
“–” or “+”
Adjust by using
“–” or “+”
Press
“–” or “+”
Example Tool:
Press “SELECT” key
Press
“SELECT” key
