Connect the Telephones
Quick Install Guide – SL2100 Terminals Type B rev 1.0 11
16/24/40 Port Panels FFV16NECBK/FFV24NECBK/FFNEC50
Converts 4/6/12 RJ45 sockets to 16/24/40 RJ45 sockets, one port per socket.
Requires 4/6/12 patch cables of the desired length and colour to connect to the SL2100 plus 16/24/40 patch
cables to connect into the customer’s panels.
Colour: black
Can be used for the ESI, SLI and Audio sockets of the IP7WW-082U-B1 card.
Note – when used for the two port SLI socket only ports 1~2 will be used.
