Configure the SL2100
Quick Install Guide – SL2100 Terminals Type B rev 1.0 22
Default Timer Setting
Description
Function
Default
Minimum Break Time
The minimum duration of a
dial pulse break
2
(10mS)
Maximum Break Time
The maximum duration of a
dial pulse break
10
(50mS)
For Time Break Recall detection set this timer
to 13 (65mS).
Do not set this item to less than 13 (65mS)
Minimum Make Time
The minimum duration of a
dial pulse make
2
(10mS)
Maximum Make Time
The maximum duration of a
dial pulse make
20
(100mS)
Minimum Hook Flash
Time
The minimum duration of a
Hook Flash/Time Break
Recall TBR
10
(100mS)
For Time Break Recall detection set this timer
to 14 (70mS).
Maximum Hook Flash
Time
The maximum duration of a
Hook Flash/Time Break
Recall TBR
20
(100mS)
For Time Break Recall detection set this timer
to 25 (125mS)
Minimum Ground-flash
Time
The minimum duration of a
ground flash
21
(105mS)
Minimum Off-hook Time
The minimum time for an
off-hook duration
19
(95mS)
No Detection Time after
Off-hook
The duration after off-hook
before dialling will be
accepted
60
(300mS)
No Detection Time after
Pulse Dial Detection
The maximum duration
after each pulse
70
(350mS)
Loop Disconnect Time
after Reversal Time
The time after line reversal
that a Loop Disconnect is
recognised
60
(600mS)
Ring Message Wait
Period
150
(750mS)
Recommended Timer Setting
Description
Setting
Minimum Break Time
2 (10mS)
Maximum Break Time
13 (65mS)
For Time Break Recall detection
Minimum Make Time
2 (10mS)
Maximum Make Time
20 (100mS)
Minimum Hook Flash Time
14 (70mS)
For Time Break Recall detection
Maximum Hook Flash Time
25 (125mS)
For Time Break Recall detection
Minimum Ground-flash Time
21 (105mS)
Minimum Off-hook Time
19 (95mS)
No Detection Time after Off-hook
60 (300mS)
No Detection Time after Pulse Dial Detection
70 (350mS)
Loop Disconnect Time after Reversal Time
60 (600mS)
Ring Message Wait Period
150 (750mS)
