GWP-G22996
- i -
INSTRUCTION MANUAL FOR DTU-70/13R9SQDx2
18kW UHF TV TRANSMITTER
......... HO2-345135-201
VOL. I
PRELIMINARY INFORMATIONS
1. Caution and Safety HO2-345135-201
- First Aid in the operation of this equipment HTD-E-3561
2. General Information HO2-345135-201
3. Functional Description HO2-345135-201
4. Operation and Adjustments HO2-345135-201
5. Maintenance HO2-345135-201
6. Warranty and Repair HO2-345135-201
7. Units and Panels
- DM-5000D Exciter HO2-344973-201
- Power Divider HO2-344648-202
- UX5000QF PA HO2-345123-201
- Power Combiner HO2-344649-201
- HPC-1605B TX Control HO2-344971-201
- SNMP Agent for TV TX HO2-344119-201
- WEB Remote Control HO2-344120-201
- NAX-77D 2
nd
Harmonic Filter HO2-345020-201
- Indoor Coaxial Feeder HO1-340761-204
- Liquid Cooling System HO2-344778-201
- Pump Rack HO2-344777-201
- Pump HO2-340857-207
- Extension Cable Unit HO2-344779-203
8. Output Coaxial Equipment
- TXASU-U-420R0 Output Coaxial Equipment HO2-345164-201
- HPC-1253 System Control (CA22) HO2-344922-201
- SNMP Agent for TV TX HO2-344140-201
- WEB Remote Control HO2-343437-201
