GWP-G22996
2 - 5
2-4 Principal Characteristics
Table 2-2
RF output power : 2.9kW / 4.3kW / 5.7kW / 7.1kW / 8.5kW / 9.9kW / 11.2kW /
12.6kW / 13.9kW / 16.5kW
Frequency range : UHF Band IV or V (470-862MHz)
Frequency stability : ±2.5×10
-7
over a period of 1 year with internal reference
Power supply
Voltage :
Voltage stability :
Frequency stability :
Power consumption :
380 / 400 / 415V, 3-phase, 4-wire
10%, -15%
2%
Approx. * kVA
Dimension
Width :
Height :
Depth :
Up to 16.5kW Over 16.5kW
615mm 1230mm
2,000mm 2000mm
1,200mm 1200mm
Ambient requirement
Temperature range :
Relative humidity :
Altitude :
Over the temperature range 0C to 45C :
Transmitter specifications are guaranteed
90% maximum
As determined by your site location
NOTE : * See TEST DATA.
