Readout value is 2's complement.

ETX (03h): End of Message

Check code

BCC: Block Check Code

Refer to the section 4.5 “Check code” for a BCC calculation.

Delimiter

CR (0Dh): End of packet

Readout value

Temperature [Celsius]

Binary Hexadecimal

+125.0 0000 0000 1111 1010

00FAh

+ 25.0 0000 0000 0011 0010

0032h

+ 0.5 0000 0000 0000 0001

0001h

0 0000 0000 0000 0000

0000h

- 0.5 1111 1111 1111 1111

FFFFh

- 25.0 1111 1111 1100 1110

FFCEh

- 55.0 1111 1111 1001 0010

FF92h
