NEC LCD Monitor

(31/137)
Item OP
code
page
OP code Parameter Remarks
INPUT RESOLUTION 02h DAh Input Resolution select
0:No mean
1:Item 1(always Auto)
2:Item 2
3:Item 3
4:Item 4
5:Item 5
Ex)
Item 1= AUTO
Item 2= -- /
1024x768 /
1400x1050 /
800x600 /
1280x960
Item 3= -- /
1280x768 /
1680x1050 /
1024x576 /
1600x900 /
Item 4= -- /
1360x768 /
-- /
-- /
--
Item 5= -- /
1366x768
-- /
-- /
--
ASPECT 02h 70h 0: No mean
1: NORMAL
2: FULL
3: WIDE
4: ZOOM
6: DYNAMIC
7: 1:1
Wide:
Dynamic
A/V mode only
ZOOM 02h 6Fh 0: No mean
1: x1.00 (100%)
2: x1.01 (101%)
|
201(C9h): x3.00 (300%)
H ZOOM 02h 6Ch 0: No mean
1: x1.00 (100%)
2: x1.01 (101%)
|
201(C9h): x3.00 (300%)
V ZOOM 02h 6Dh 0: No mean
1: x1.00 (100%)
2: x1.01 (101%)
|
201(C9h): x3.00 (300%)
H POS 02h CCh 0: Left side
|
200(C8h): Right side
Zoom Control
V POS 02h CDh 0: Down side
|
200(C8h): Up side
IMAGE FLIP 02h D7h 0: No mean
1: NONE
2: H FLIP
3: V FLIP
4: 180 ROTATE
