Cabinet Dimensions
The following drawings show the cabinet dimensions.
Dimensions are in inches. For millimeters multiply by 25.4.
ventilation
2.30
7.36 1.40
10.24
10.83
4.84
4.72
3.17
2.76
4.09
3.62
Ø
3
.
1
5
4.21
12.32
2.24
3.27
distance to A1 & A2
distance to B
ventilation
