English-11
English
Controls
1 Power Switch To turn the monitor on and off.
2 LED Indicates that the power is on.
Turns off automatically, when the luminance is stabilized.
3 Front Sensor For luminance stabilization and calibration.
4 Ambient Light Sensor Measures ambient light during calibration process.
5 + (plus) Button To open the OSD menu (On Screen Display)
1
st
click – Display information
2
nd
click – Present operating state
3
rd
click – DICOM conformance test
4
th
click – OSD menu off (otherwise the OSD menu disappears in 15 sec.)
6 – (minus) Button Same as + (plus) Button
7 Main power switch Main power supply switch.
OSD (On Screen Display)
Display information
Model
Serial Number
Maintenance Information
Total Operating Hours
EDID Data Status
Operating Hours Since The Last Calibration
Display Mode*
Present operating state
Current Luminance
Confi guration Number
Luminance Setting
Gamma Setting
Ambient Light
Current input source
DICOM conformance test
Result of the last test
Continuous lighting time of the backlight
Luminance status
*: MD211G5 only.
