English-12
Specifi cations - MD212G3
Monitor Specifi cations MD212G3 Notes
LCD panel color Clear Base
LCD 21.3-inch (54 cm), monochrome, TFT active matrix, anti-glare
Pixel pitch (H x V) 0.212 x 0.212 mm
Display area (H x V) 324.86 x 433.15 mm
Pixel (H x V) 1536 x 2048
Grayscale 256 steps of gray out of a palette of 12277
10-bit (1024) simultaneously displayable grayscale in DisplayPort input
Backlight Edge Light Type with white LED
LCD Optical characteristics (typ.) Viewing angle: 176° horizontal/vertical (contrast ratio ≥ 10:1)
Contrast ratio: 1400:1 (Viewing angle perpendicular to LCD panel)
Luminance DICOM calibrated 400 cd/m
2
as factory default
Maximum 600 cd/m
2
(1700 cd/m
2
typ. as LCD component)
Input sync signal DVI 1.0 compliant, DisplayPort 1.1a compliant
Available resolution 640 x 480
800 x 600
1024 x 768
1536 x 2048 (at Fv=30/60Hz)
2048 x 1536 (at Fv=30/60Hz)
Input connectors DVI 24-pin connector, DisplayPort connector
Power Supply AC 100-240 V ~ 50/60 Hz
Current Rating 1.5 - 0.6 A
USB Hub USB Rev. 2.0 compliant, Self-powered
USB upstream port (x1), USB downstream ports (x2)
Ambient conditions Temperature:
Humidity (no condensation):
Air pressure:
Operating: 5 - 35°C, Transport / Storage: -20 - 60°C
Operating: 20 - 80%, Transport / Storage: 10 - 85%
Operating: 700 - 1060hPa, Transport / Storage: 266 - 1060hPa
Dimensions & weight Net: 367.0 x 487.3/583.8 x 227.6 mm (W x H x D: Portrait) approx. 10.8 kg
14.4 x 19.2/23.0 x 9.0 inches (W x H x D: Portrait) approx. 23.8 lbs
Safety certifi cations ANSI/AAMI ES60601-1:2005, CAN/CSA-C22.2 No. 60601-1:08, FCC-B, CE-MDD, VCCI-B
NOTE: Technical specifi cations are subject to change without notice.
