Self Calibration
Self Calibration will compensate for a yellow color shift that typically occurs with long-term LCD usage. All PICTURE MODES
are updated when Self Calibration is performed.
Figure S.2
Figure S.3
Figure S.1
USB downstream
USB color sensor
USB icon ( )
is on the
other side
1. Use “LEFT” or “RIGHT” to select SELF in the MODE selection. Press “UP” or “DOWN” to move to the next selection.
2. The procedure will ask for the USB color sensor to be placed on the center of the display panel (Figure S.2). Tilt the display
panel approximately 5° backward and place the USB color sensor in the center of the display panel (Figure S.1).
NOTE: Place the USB color sensor fl at against the LCD to avoid external light contamination. DO NOT press the USB color
sensor against the display panel.
Press “SELECT” to start the calibration. Stand-alone calibration may take several minutes depending on user settings.
3. After the CALIBRATION SUCCEEDED message appears (Figure S.3), press SELECT.
4. To end the calibration mode, press “EXIT”.
