SET the user switch
CONTRAST VR
:
Fully
clockwise
BRIGHTNESS VR
:
Fully clockwise
COLOR SW
:
Left most position (position "N")
SYNC
:
Left side (OFF)
Adjustment Signal and Timing
Adjustment signals and Timing
(Nos.l-9
:
Preset signals)
Sync Polarity
No. Signal
SYNC
horizontal vertical
1
VGA 350
SEPARATE
positive
negat i ve
2 VGA 400
SEPARATE
negat i ve positive
3
VGA 480
SEPARATE
negative negat i ve
4
8514A
SEPARATE
positive
positive
inter less
5
MAC- II
SYNC ON GREEN negative negative
11
6
800x600(56)
SEPARATE
positive positive The sync polarity
can also be negative
14
27kHz(55)
SEPARATE
positive negat i ve
Fh=27kHz
FV=55kHz
15
62kHz(90)
SEPARATE
negative positive
Fh=62kHz
FV=90kHz
*1
When SYNC On GREEN
output,simultaneously
output a
COMPOSITE SYNC signal to the H SYNC
line. V
SYNC connect to ground.
COMPOSITE SYNC polarity is NEG/NEG.
(SERRATION is
ON(IH))
*2
Video
Horizontal size
1/8
of width
Vertical size
l/4
of height
*3 Crosshatch Vertical
lines:17
Horizontal
lines:13
*4
If the
cond
to output
s
fol lowing
ition
of the signal generator makes it impossible
ignals with an
Fh
of exactly
27.00kHz
56kHz,use
the
27kHz
:
62kHz
:
Largest value
s
27. OOkHz (EX: 26.99)
Smallest value
2
62.OOkHz
(EX:62.01)
A
25
