English-16
Specifications
Monitor Specifications MultiSync E245WMi Monitor Notes
LCD Module Diagonal:
Viewable Image Size:
Native Resolution (Pixel Count):
61.13 cm/24 inches
61.13 cm/24 inches
1920 x 1200
Active matrix; thin film transistor (TFT) liquid crystal
display (LCD); 0.270 mm dot pitch; 250 cd/m
2
white
luminance; 1000:1 contrast ratio (typical), (10000:1
Contrast ratio, DV MODE ON).
Input Signal
DisplayPort: DisplayPort Connector: Digital RGB DisplayPort Complies with Standard V1.2,
applicable to HDCP
DVI: DVI-D 24pin: Digital RGB DVI (HDCP)
VGA: 15pin Mini D-sub: Analog RGB
Sync
0.7 Vp-p/75 ohm
Separate sync.TTL level Positive/Negative
Display Colors 16,777,216 Depends on display card used.
Synchronization Range Horizontal:
Vertical:
31.5 kHz to 77.0 kHz
56 Hz to 60 Hz
Automatically
Automatically
Viewing Angle Left/Right:
Up/Down:
±89°(CR>10)
±89°(CR>10)
Resolutions Supported (Some systems may
not support all modes listed).
640 x 480*
1
at 60 Hz
800 x 600*
1
at 56 Hz to 60 Hz
1024 x 768*
1
at 60 Hz
1280 x 960*
1
at 60 Hz
1280 x 1024*
1
at 60 Hz
1400 x 1050*
1
at 60 Hz
1440 x 900*
1
at 60 Hz
1600 x 1200*
1
at 60 Hz
1680 x 1050*
1
at 60 Hz
1920 x 1200 at 60 Hz........................................... NEC DISPLAY SOLUTIONS cites recommended
resolution for optimal display performance.
Active Display Area Landscape: Horiz.:
Vert.:
Portrait: Horiz.:
Vert.:
518.4 mm/20.4 inches
324.0 mm/12.8 inches
324.0 mm/12.8 inches
518.4 mm/20.4 inches
AUDIO
AUDIO Input: STEREO Mini Jack:
DisplayPort Connector:
Analog Audio
Digital Audio
Stereo L/R 1.0 Vrms 20 Kohm
PCM 2ch 32, 44.1, 48 kHz (16/20/24bit)
Headphone Output: STEREO Mini Jack: Headphone Impedance 32 Ohm
Speakers Practical Audio Output: 1.0 W + 1.0 W
Power Supply AC 100 - 240 V, 50/60 Hz
Current Rating 0.65 - 0.35 A
Dimensions Landscape:
Portrait:
Height Adjustment:
556.2 mm (W) x 394.2 - 504.2 mm (H) x 213.9 mm (D)
21.9 inches (W) x 15.5 - 19.9 inches (H) x 8.4 inches (D)
361.6 mm (W) x 572.6 - 601.5 mm (H) x 213.9 mm (D)
14.2 inches (W) x 22.5 - 23.7 inches (H) x 8.4 inches (D)
110 mm / 4.3 inches (Landscape orientation)
28.9 mm / 1.1 inches (Portrait orientation)
Weight 5.9 kg (13.0 lbs) (with stand)
Environmental Considerations
Operating Temperature:
Humidity:
Altitude:
Storage Temperature:
Humidity:
Altitude:
5°Cto35°C/41°Fto95°F
20% to 80%
0 to 6,562 Feet/0 to 2,000 m
-10°Cto60°C/14°Fto140°F
10% to 85%
0 to 40,000 Feet/0 to 12,192 m
*1 Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is normal and
necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each dot on the screen is actually one
pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
NOTE: Technical specifications are subject to change without notice.
