1 Door latch - If the door is opened while the
oven is operating, the magnetron will
automatically shut off.
2 Door seal - The door seal maintains the
microwave within the oven cavity and
prevents microwave leakage.
3 Oven cavity
4 Spatter shield - Protects the microwave
outlet from splashes of cooking foods.
5 Safety interlock system - Prevents the
oven from operating while the door is
opened.
6 Door release button - Pushing this button
stops oven operation and opens the door.
7 Glass cooking tray - Made of specical heat
resistant glass. The tray must always be in
proper position before operating.
8 Roller guide - Supports the glass cooking
tray.
9 Door screen - Allows viewing of food.
The screen is designed so that light can
pass through, but not the microwaves.
FEATURES DIAGRAM
