NEC NP01WK - Dimensions of Parts

ENG-6
ENG-7

Dimensions of Parts:
(unit: mm)
The dimensions of the positions of the wall fixation screws (bolts) of the wall adapter are
described.
142
100
100
142
100
100
189
90-190
189
219
120
320
280
Projector bottom surface
(including the feet)
533 (minimum) -733 (maximum)
The center of the wall adapter
(central axis)
Central axis
Projector posterior surface
