84
6. Using On-Screen Menu
Selecting Aspect Ratio [ASPECT RATIO]
Screen Type 4:3 SCREEN (VIDEO) Screen Type WIDE SCREEN (VIDEO) RGB
Aspect Ratio allows you to select the best Aspect mode to display your source image.
When screen type 4:3 SCREEN is selected for the source, the following selections will display:
For VIDEO
4:3 ......................... Standard 4:3 aspect
LETTERBOX
........... Reduced to display the true aspect with black borders on top and bottom
WIDE SCREEN
....... Left & Right stretched with black borders on top and bottom
ZOOM
.................... Left & Right stretched. Left & Right sides cut. Available for 4:3 only.
When screen type WIDE SCREEN is selected for the source, the following selections will display:
For VIDEO
4:3 WINDOW ......... Reduced to display the true aspect with black borders on right and left
LETTERBOX
........... Standard 16:9 aspect
WIDE SCREEN
....... Left and right stretched to display the true aspect
4:3 FILL
................. Stretched to display in 16:9 aspect ratio
For RGB
4:3 ......................... For a video signal with an aspect ratio of 4:3
5:4 ......................... For a video signal with an aspect ratio of 5:4
16:9 ....................... For a video signal with an aspect ratio of 16:9
16:10 ..................... For a video signal with an aspect ratio of 16:10
15:9 ....................... For a video signal with an aspect ratio of 15:9
NOTE:
•
You can adjust image position vertically for a source with black borders on top and bottom. (
→
page 99)
• When [NATIVE] is selected in [RESOLUTION], [ASPECT RATIO] is not available.
NOTE: Please note that using this projector for the purpose of commercial gain or the attraction of public attention in a venue
such as a coffee shop or hotel and employing compression or expansion of the screen image with a [ASPECT RATIO] or [SCREEN]
setting may raise concern about the infringement of copyrights which are protected by copyright law.
