NEC Display Solutions of America, Inc.
NP4100W Installation Guide
Desktop and Ceiling Mount v 1.0
www.necdisplay.com NP4100W Page 7 of 10
Cabinet Dimensions
The following diagrams show the cabinet dimensions for the NP4100W.
Dimensions are in inches. For millimeters multiply by 25.4.
19.88
5.37
7.76
8.23 15.16
9.45
3.35
11.78
0.47
2.11
5.93
4.925.74
2.14
3.89
4.60
4.90
Air Exhaust
Air IntakeAir Intake
Air Intake
Filter
Filter
Filter
Speaker
Speaker
Lamp & Color Wheel Cover
For Mount
M4*12mm max
To Next Page
