NEC NP410W - Cabinet Dimensions

NEC Display Solutions of America, Inc.
NP410W/NP510W Installation Guide
Ceiling Mounted and Desktop Rev 1.2
www.necdisplay.com NP410W/NP510W Page 3 of 6
Cabinet Dimensions
The following drawings show the cabinet dimensions.
Dimensions are in inches. For millimeters multiply by 25.4.
Lens Center
Lens Center
Zoom Lever
Focus Lever
Lamp
I
n
t
a
k
e
Exhaust
E
x
h
a
u
s
t
F
ilt
e
r
