NEC NP500WS - Cabinet Dimensions

NEC Display Solutions of America, Inc.
NP500WS Installation Guide
Ceiling Mounted and Desktop Rev 1.6
www.necdisplay.com NP500WS Page 3 of 7
Cabinet Dimensions
The following drawings show the cabinet dimensions.
Dimensions are in inches. For millimeters multiply by 25.4.
NP 600S
Lamp
Lens Center
Focus Lever
Lens Center
Exhaust
