Cabinet Dimensions
The following drawings show the cabinet dimensions.
Dimensions are in inches. For millimeters multiply by 25.4.
NP 600S
Lamp
Lens Center
Focus Lever
Lens Center
Exhaust
E
x
h
a
u
s
t
I
n
t
a
k
e
F
il
t
e
r
